Natural Silver Almiunum Spigot Truss For Outdoor Big Events 24m Max Span
Descriptions:
Aluminum Spigot Truss is made of the material of international standard 6082, with the advantages of beautiful appearance,small volume, easy to set up and transport, it also has the advantages of excellent compressive and anticorrosive performance; the truss average loading can meet many kinds of performances, business conferences audio equipment requirements. Other irregular shapes can be customized according to your requirements.
Specificaton:
Size of Truss: 520*760mm
Connection: Spigot
Truss main tube: Diameter Ø 50mm , Thickness 3mm
Truss sub-tube: Diameter Ø 50mm , Thickness 2mm
Truss brace tube: Diameter Ø 30mm , Thickness 2mm
| Size of Truss | 450x600mm | 520x760mm | 600x760mm | 520x1000mm |
| Connection | Spigot/Bolt | Spigot/Bolt | Spigot/Bolt | Spigot |
| Truss main tube | Diameter Ø 50mm , Thickness 3mm | Diameter Ø 50mm , Thickness 3mm | Diameter Ø 50mm , Thickness 3mm | Diameter Ø 50mm , Thickness 3mm |
| Truss sub-tube | Diameter Ø 50mm , Thickness 2mm | Diameter Ø 50mm , Thickness 2mm | Diameter Ø 50mm , Thickness 2mm | Diameter Ø 50mm , Thickness 2mm |
| Truss brace tube | Diameter Ø 30mm , Thickness 2mm | Diameter Ø 30mm , Thickness 2mm | Diameter Ø 30mm , Thickness 2mm | Diameter Ø 30mm , Thickness 2mm |
| Truss Joint | 50x40mm | Ø50/60mm,50x40mm | Ø50/60mm,50x40mm | 50x40mm |
| Max Loading | 630-3400kg | 840-4100kg | 840-4100kg | 780-4700kg |
| Max Span | 22m | 24m | 24m | 30m
|
Applications:
1. Celebration services: opening ceremonies, anniversary celebrations, housewarming celebration; opened the ribbon-cutting, the launching ceremony, the unveiling ceremony, the groundbreaking ceremony for the completion ceremony, capping ceremony, the foundation stone laying ceremony, , the signing ceremony, the listing ceremony,, public relations etiquette; promotion of new products, awards ceremony;
2. Business services: press conferences, new product launches, the various types conferences such as for investment,order, awards, the annual meeting, customer appreciation, sightseeing exchanges
3. Performances service: Business promotional performances, thank and return banquet, theatrical show, the models show,the ethnic features performances, Chinese and foreign star invitation; stage design, and production of the lighthouse for performing arts, performances facility ,stage lighting truss.
Other Information of Product
Warranty: 2 Years
Sample: Depends on the quantity of order.
Design: Any designs can be customized.
Photos:
Welcome to contact us for long term cooperation!
